Gabion mesh

Gabion Mesh is a durable and flexible wire mesh solution widely used in civil engineering, erosion control, slope stabilization, riverbank protection, and retaining wall projects. It is typically manufactured from high-quality galvanized steel wire or PVC-coated steel wire and formed into a double-twisted hexagonal mesh structure for excellent strength and flexibility.

Phone ：+86 19006356480

WhatsApp : +86 19006356480

Email : admin@huanyugeo.com

Product Parameters

Gabion Mesh can be supplied in various mesh sizes, wire diameters, and dimensions to meet different project requirements. When filled with natural stones or rocks, gabion baskets create strong and permeable structures that help prevent soil erosion while providing long-term stability.

With excellent corrosion resistance, structural strength, and easy installation, Gabion Mesh is an economical and reliable choice for both infrastructure projects and landscape applications.

Product	Gabion Mesh
Material	Low carbon steel wire or Galvanized steel wire
Surface Treatment	Hot dipped galvanized or Electro-galvanized
Hole Shape	Hexagonal
Opening Size	3/8″ – 4″
Wire Diameter	0.4 mm – 5 mm
Packaging	In roll
Roll Length	5 – 50 m or as per your requirements
Delivery Time	7 – 30 days after receipt of deposit
Applications	Chicken coops, rabbit fencing, rockfall netting, gabion baskets, slope protection, etc.

Mesh			Min. Galv.	Width	Wire Gauge (Diameter)
Inch	mm	Tolerance (mm)	G/SQ.M	Width	BWG
3/8"	10mm	±1.0	0.7mm - 145	2' - 1M	27, 26, 25, 24, 23
1/2"	13mm	±1.5	0.7mm - 95	2' - 2M	25, 24, 23, 22, 21
5/8"	16mm	±2.0	0.7mm - 70	2' - 2M	27, 26, 25, 24, 23, 22
3/4"	20mm	±3.0	0.7mm - 55	2' - 2M	25, 24, 23, 22, 21, 20, 19
1"	25mm	±3.0	0.9mm - 55	1' - 2M	25, 24, 23, 22, 21, 20, 19, 18
1-1/4"	31mm	±4.0	0.9mm - 40	1' - 2M	23, 22, 21, 20, 19, 18
1-1/2"	40mm	±5.0	1.0mm - 45	1' - 2M	23, 22, 21, 20, 19, 18
2"	50mm	±6.0	1.2mm - 40	1' - 2M	23, 22, 21, 20, 19, 18
2-1/2"	65mm	±7.0	1.0mm - 30	1' - 2M	21, 20, 19, 18
3"	75mm	±8.0	1.4mm - 30	2' - 2M	20, 19, 18, 17
4"	100mm	±8.0	1.6mm - 30	2' - 2M	19, 18, 17, 16

Note: Special size and specification can be customized.
